| 编 号 | D1(mm) | D2(mm) | L1(mm) | L2(mm) | L3(mm) | L4(mm) | B1(mm) | 电缆直径范围 |
| Item NO. | Cable range | |||||||
| PG-07 | 12.1 | 8.7 | 8.3 | 5 | 15 | 13.8 | 6.9 | 3.5~6 |
| PG-09 | 16.2 | 11.1 | 8.7 | 4.6 | 16.1 | 15.7 | 8.9 | 4~8 |
| PG-11 | 18.2 | 13.4 | 8.7 | 5.1 | 18.1 | 17.9 | 11.3 | 5~10 |
| PG-13.5 | 20.1 | 15.5 | 8.9 | 5 | 19.2 | 18.3 | 12.8 | 6~12 |
| PG-16 | 22.3 | 17.6 | 11.3 | 5.2 | 20.2 | 18.1 | 13.7 | 10~14 |
| PG-19 | 24.1 | 19.1 | 11.1 | 5.1 | 21.1 | 20.5 | 15.8 | 12~15 |
| PG-21 | 26.7 | 21.4 | 11.1 | 5.1 | 23 | 22 | 17.4 | 13~18 |
| PG-24 | 30.1 | 24.8 | 12.8 | 5.8 | 23.9 | 23.7 | 23.1 | 15~22 |
| PG-29 | 35.9 | 28.8 | 11.9 | 6.9 | 24.4 | 23.5 | 25.3 | 18~25 |
| PG-36 | 46.4 | 39.1 | 16 | 7.8 | 30.7 | 27.3 | 31.9 | 22~32 |
| PG-42 | 53.9 | 46.7 | 15.4 | 7.9 | 33.2 | 28.5 | 37.1 | 30~38 |
| PG-48 | 60.2 | 52.6 | 18 | 7.9 | 35.5 | 30.3 | 45.1 | 34~44 |
| PG-63 | 70.6 | 63.9 | 28.9 | 8.9 | 41.4 | 41.3 | 49.3 | 42~54 |
